Audi Quattro 1980-91
See specifications below illustration
Page 268
Audi Quattro 1980-91 specifications
Specifications

Engine: (VW) inline 5 cylinder, water cooled, ohv

Bore & Stroke: 79.5mm x 86.4mm

Displacement: 2,144cc

Compression ratio: 7 to 1

Carburation: petrol, Bosch K-Jetronic

Power output: 160bhp / 119.3kw at 5,500rpm

Torque:170 b/ft / 230.4Nm at 3,000rpm

Maximum speed: 128mph / 206.0km

Acceleration: 0-60mph 8.2secs

Approx. fuel consumption: 23.5mpg

Brakes: Hydraulic, discs front & rear

Transmission: 5 speed manual, 4WD

Construction: monocoque all steel body

Steering: Rack & pinion, PA

Turning circle: 37ft 1in

Suspension: independant coil front & rear

Wheels & Tyres: 15in, 5 stud alloy, 205/60 VR 15 tyres

Kerb weight: 1,350kg / 2,975 lbs

Tank capacity: 19.8 imp gals / 90 Litres / 23.8 US gal

Dimensions

Wheelbase: 99.4in / 2,524mm

Track, front: 55.9in / 1,42mm, rear: 57.4in / 1,458

Overall length: 173.4in / 4,404mm

Width: 67.8in / 1,723mm

Height: 52.9in / 1.344mm

Ground clearance: 4.5in / 115mm

Production

Audi Quattro production 1980-1991: 11,452 built, Ingolstadt, Germany
