Ford Sierra XR4i 1983
See specifications below illustration
Page 39
Ford Sierra XR4i 1983 Specifications
Engine
V 6 cylinder fuel injection Displacement: 2,792cc
Bore: 93.0mm
Stroke: 68.5mm
Compression ratio: 9.2 / 1
Valves: 12, overhead,
2 per cylinder,
Power output: 150bhp
at 5,700rpm

Performance
Maximum speed: 129mph
Acceleration: 0-60mph 7.7secs
Overall fuel consumption:
21.4mpg
drag coefficient: 0.320

Transmission
4-foward speed, manual
all syncromesh
rear wheel drive

Construction
Pressed steel monocoque

Brakes
Hydraulic PA,
Front: discs
Rear: drum

Steering
Rack and pinion PA

Suspension
Front & rear: independent
Coil (MacPherson strut),
anti roll bars

Wheels
13in, alloy

Dimensions & Weight
Wheelbase: 102.6in
Track front: 57.1in
Track rear: 57.7in
Overall length: 175.5in
Overall width: 66.0in
Overall height: 54.8in
Kerb weight: 2,656lbs
Fuel tank: 13.2gals
