Mazda MX-5 NA 1.8i 1994
See specifications below illustration
Page 225
Mazda MX-5 NA 1.8i 1994 specifications
Engine: (BP-4W rs): 4 cylinder inline, 16 valve DOHC, aluminium head & block, longitudal

Bore: 83mm

Stroke:85mm

Displacement: 1,840cc

Compression ratio: 9.4 to one

Carburation: Bosch L-Jetronic petrol injection

Max power: 128bhp at 6,500rpm, torque: 110 lbs/ft at 5,000rpm

Max speed: 115mph

0-60mph: 8.2secs

O.F.C.: 32.6mpg (Imp.)

Transmission: RWD, 5-speed, all synchro, final drive: 4.1

Steering: rack and pinion, 31.8 ft turning circle

Suspension: independent, coil & double wishbone, anti-roll bars front and rear

Brakes: PA, hydraulic, front: ventilated disc, rear: solid disc. ABS

Construction: all steel monocoque, aluminium bonnet

Wheels & tyres: 5.5J x 14in 7-spoke alloy, R 14 H tyres

Wheelbase: 89.2in

Track F: 55.5in, R: 56.3in

Overall length: 165.5in

Overall width: 65.9in

Overall height: 48.2in

Ground clearance: 5.5

Kerb weight: 19.09cwt

Fuel tank: 9.9Imp gal

NA Production: 1989-97 ?Hiroshima, Japan.
Designed By: Tsutomu Matano and Shunji Tanaka
