Porsche 911 Turbo (930) 1978-89 (3.3L model)
See specifications below illustration
Page 187A
Porsche 911 Turbo 930 1978-89 (3.3L model) specifications
Engine (Boxer 6): All aluminium, 6 Cylinder, horizontally mounted, 12 overhead valves, petrol injection, single turbo charged, air cooled, intercooler (under ‘tea tray’)

Bore & stroke: 97mm x 74mm

Displacement: 3,299cc

Compression ratio: 7.0 to 1

Maximum speed: 249.4km/h (155mph)

Acceleration: 0-96.5km/h 5secs (0-60mph 5sec)

Max power: 210.3kw (282bhp) at 5.500rpm

Max torque: 431 Nm / 318 lb-ft

Drag coefficient: 0.39

Construction: pressed steel monocoque

Ave. fuel consumption: 19mpg

Transmission: 4 forward speed manual, rear engined, rear wheel drive

Brakes front & rear: P.A. dual circuit, ventilated discs

Suspension: Coil McPherson Strut front & rear, Panhard at rear

Steering: PA rack & pinion

 Turning circle: 10.7m (35.1ft)

Wheels: Aluminium bolt-on 5 stud, 7J x 16 front, 9J at rear

Tyres front: 205/55 ZR 16, rear: 245/45 ZR 16

Wheelbase: 2,273mm

Track front: 1,433mm, rear: 1,501mm

Overall length: 4,291mm

Overall width: 1,775mm

Overall height: 1,311mm

Ground clearance: 119mm

Tank capacity: 85.2 litres (18.7 UK gal)

Unladen weight: 1,378.9kg (3,040 lbs)

911 Turbo (930) production: 1974-89, 3.3L model 1978-89
21,589 produced, Stuttgart, Germany
