Porsche 997 Carrera 4S 2004-12
See specifications below illustration
Page 209B
Porsche 997 Carrera 4S 2004-12 specifications
Drivetrain layout: rear engine, AWD, ?2-door, 2+2 pass

Engine: F-6, DOHC, 4 valves/cyl, alum block & heads

Displacement: 3,824cc

Compression ratio: 11.8 to 1

Bore & stroke: 99mm x 82.8mm (3.9in x 3.26in)

Maximum speed: 174mph/297km

Acceleration: 0-60mph 4.6sec

Max power: 385hp at 6,500rpm

Max torque: 420Nm at 4,400rpm

Construction: pressed steel monocoque

Fuel consumption: urban 16mpg, overall 24mpg

Transmission: 6 speed manual, all wheel drive

Brakes front & rear: Dual circuit, ABS F/R 13in ventilated disc

Suspension: Struts, anti-roll bar; multilink, ?coil springs, anti-roll bar

Steering: PA rack & pinion, 3 turns lock to lock

Wheels: Aluminium bolt-on 5 stud, 8J x 18in front, 11J at rear

Tyres front: 235/35RZR19, rear: 305/30ZR19

Wheelbase: 92.5in/2,350mm

Track front: 58.5in/1,488mm, rear: 59.8in/1,548mm

Overall length: 174.6in/4,435mm

Overall width: 72in/1,852mm

Overall height: 51in/1,300mm

Ground clearance: 4in/100mm

Turning Circle: 34.8ft

Tank capacity: 14.8 Imp. gal (68 litres, 17.8 US US gal)

Kerb weight: 3,240 lb (1,495kg) )

Production: 2004-2012, Stuttgart, Germany
