Jaguar XJS 4.0 Convertible 1993-96 ‘big bumper’
See specifications below illustration. to JAGUAR page
Page 156F
Jaguar XJS 4.0 Convertible 1993-96 specifications ‘big bumper’
Engine (4.0 AJ16)
6 Cylinder in line, fuel injection
Valves: 24
Bore & Stroke: 91mm x 102mm
Displacement: 3,980cc
Compression ratio: 9.7 to 1
Power output: 223bhp at 5,250rpm
Torque377 Nm at 3,650rpm

Performance
Maximum speed: 140mph
Acceleration: 0-60mph 8.6secs
Overall fuel consumption: 23.15mpg

Transmission
4-speed manual, rear wheel drive

Construction
Unitary, all steel

Brakes
Servo assisted discs front & rear
Steering
Power assisted rack and pinion,

Suspension
Front & Rear: independent wishbone and coil
radius arms at rear

Wheels
5 stud alloy with 215/70x15 tyres

Dimensions & Weight
Wheelbase: 102in
Track - front: 58.3in
Track - rear: 58.9in
Overall length: 191.7in
Overall width: 70.6in
Overall height: 47.8in
Ground clearance: 5.5in
Kerb weight: 38.4cwt
Petrol tank capacity: 20 Imp gallons

XJS 'facelift'Production 1991-96
27,406 built
Coupé: 8,832
Convertible: 18,574

XJS Production 1975-96
115,413 built
