See specifications below illustration
Page 019
Engine
4 cylinder in-line,
Valves: side, 8
Displacement: 933cc
Bore: 56.6mm
Stroke: 92.5 mm
Compression ratio: 6.3 - 1
Valves (side): 2 per cylinder
Carburettors: one
Power output: 23.4bhp at 4,000rpm
Performance
Maximum speed: 60.4mph
Acceleration: 0-50 mph 35.3 secs
Overall fuel consumption: 36mpg
4 cylinder in-line,
Valves: side, 8
Displacement: 933cc
Bore: 56.6mm
Stroke: 92.5 mm
Compression ratio: 6.3 - 1
Valves (side): 2 per cylinder
Carburettors: one
Power output: 23.4bhp at 4,000rpm
Performance
Maximum speed: 60.4mph
Acceleration: 0-50 mph 35.3 secs
Overall fuel consumption: 36mpg
Transmission
3 forward speed manual Rear wheel drive
Construction
Pressed steel body on steel channel chassis
Brakes
Mechanical - rod and ball socket joints,
drums all round
Pressed steel body on steel channel chassis
Brakes
Mechanical - rod and ball socket joints,
drums all round
Suspension
Front & Rear: Semi-elliptic leaf springs
Steering
Rack and pinion
Wheels
17in, pressed steel
Dimensions & Weight
Wheelbase: 7ft 6in
Track F: 3ft 7in
Track R: 3ft 7in
Overall length: 12ft 8.2in
Overall width:4ft 7.9in
Overall height: 5ft 4.2in
Ground clearance: 8.8in
Kerb weight: 1,695lbs
Fuel tank 7gals
Production
1938-1939
65,598 produced
Wheelbase: 7ft 6in
Track F: 3ft 7in
Track R: 3ft 7in
Overall length: 12ft 8.2in
Overall width:4ft 7.9in
Overall height: 5ft 4.2in
Ground clearance: 8.8in
Kerb weight: 1,695lbs
Fuel tank 7gals
Production
1938-1939
65,598 produced
