Morris 8 Tourer 4 seater 1935-39
See larger specifications below illustration.
Personalised example to Morris page
Page 066B
Morris 8 Tourer 4 seater 1935 -39 Specifications
Engine
4 Cylinder in line
Bore & Stroke: 57 mm x 90 mm
Displacement: 918.6 cc
Valves: side, 8
Compression ratio: 6.6:1
Carburation: single SU
Power output: 27.5bhp at 4,400rpm

Performance
Maximum speed: 59.2mph
Acceleration: 0-50 mph 41.9secs
Overall fuel consumption: 38-42mpg

Ignition
6 volt coil, 14mm Champion L10 plugs
Transmission
Clutch: single, dry plate
Gearbox: 3-speed, synchromesh on
2nd and top
Ratios: 5.375, 5.729 & 16.85 to 1 reverse 22.84 to 1
Propellar Shaft: Shaft and spiral bevel

Chassis
Double box section type

Brakes
Lockheed Hydraulic on 8in drums

Steering
Bishop cam

Suspension
Semi eliptic front and rear with Armstrong hydraulic shock absorbers
Wheels & Tyres
17in Magna detachable wire
450 x 17in crossply

Dimensions & Weight
Wheelbase: 7ft 6in
Track - front: 3ft 9in
Track - rear: 4ft 3.5 in
Overall length: 11ft 9in
Overall width: 4ft 6.5in
Overall height: 5ft
Ground clearance: 6.8in
Turning circle: Left 33ft 10in,
right: 36ft
Kerb weight: 13.97 cwt
Tank capacity: 5.5 gallons
Sump capacity: 5 pints
