Austin Healey 3000 MKIIA 1963
See specifications below illustration.
Page 38H
Austin Healey 3000 MKIIa 1963 specifications
Engine
OHV 6 Cylinder in line
Bore: 83mm, Stroke: 88mm
Displacement: 2,912cc
Compression ratio: 9:1
Carburettors: triple HS4 SU
Power output: 132bhp at 4700rpm

Performance
Maximum speed: 116 mph
0-60mph: 9.8secs

Construction
Pressed steel box section frame
welded to all metal body

Transmission
Rear wheel drive
Manual 4 speed, with overdrive
final drive: 3.91 to 1
Beam rear axle

Brakes
Hyraulic Girling
Front: 11in disk, Rear: 11in drums
Suspension
Front: Independent coil and wishbones
Rear: Live axle, half-eleptic springs
Shock absorbers: lever-arm front
and rear

Wheels
Knock-on 15in wire wheels
with 5.5 x 15in crossply tyres

Dimensions & Weight
Wheelbase: 7ft 8in
Track - front: 4ft
Track - rear: 4ft 1in
Overall length: 13ft 1in
Overall width: 5ft
Unladen weight: 20.5cwt

Production
MkII 1961-62: 5,450
MkIIa Convertible 1962-64: 6,113
