Lotus Elan+2 1967-75
See specifications below illustration .
Page 194
Lotus Elan+2 1967-75 specifications
Engine (Ford): 4 cylinder inline, twin OHC, aluminium head cast iron block, 5 crankshaft bearings,

Bore: 82.57mm

Stroke: 72.75mm

Displacement: 1,558cc

Compression ratio: 10.3 to one

Carburettors: two 40DCOE twin choke Webers

Max power: 118bhp at 6,250rpm,

Max speed: 120mph

0-60mph: 7.9secs

O.F.C.: 26mpg (Imp.)

Transmission: RWD, 4-speed, synchromesh on all forward gears. 3.7:1 hypoid final bevel drive

Steering: rack and pinion, collapsible column, 28ft turning circle

Suspension: independent coil & wishbone, front and rear

Brakes: servo assisted hydraulic 10in disc front and rear

Construction: GRP body on steel backbone chassis

Wheels & tyres: centre lock ventilated 4.5J 13in pressed steel disc,155 x 13in radial ply tyres

Wheelbase: 96in

Track F: 54in, R: 55in

Overall length: 169in

Overall width: 66in

Overall height: 46in

Ground clearance: 6in

Kerb weight: 18.63cwt

Production: 1967-75 approx 3,300 built
