See specifications below illustration . Please note: spare wheel on boot can be deleted if your car is without this
Page 160C
Engine
4 cylinders OHC
5 crankshaft bearings
Bore: 85.7mm, Stroke: 85.7mm
Displacement: 1,978cc
Valves: Pushrod/overhead 8
Compression ratio: 10.0 to 1
Carburettors: two SU
Power output: 114bhp at 5,500rpm
Torque: 126 ft/lb at 3,500rpm
Performance
Maximum speed: 108mph
0-50mph: 8.6secs
0-60mph: 12.2secs
Approx fuel consumption: 22.4mpg
Transmission
4-speed manual
rear wheel drive
Brakes
Power assisted
Front: discs, Rear: inboard disc
4 cylinders OHC
5 crankshaft bearings
Bore: 85.7mm, Stroke: 85.7mm
Displacement: 1,978cc
Valves: Pushrod/overhead 8
Compression ratio: 10.0 to 1
Carburettors: two SU
Power output: 114bhp at 5,500rpm
Torque: 126 ft/lb at 3,500rpm
Performance
Maximum speed: 108mph
0-50mph: 8.6secs
0-60mph: 12.2secs
Approx fuel consumption: 22.4mpg
Transmission
4-speed manual
rear wheel drive
Brakes
Power assisted
Front: discs, Rear: inboard disc
Steering
Rack and pinion
Suspension
Front: Independent coil, anti-roll bar
Rear: de Dion tube suspension
Wheels
5 stud, 16in pressed steel
6.50 x 14in radial tyres
Construction
Non-stressed steel outer panels bolted on unitary steel body with safety cage
Dimensions & Weight
Wheelbase: 103.3in
Track - front: 53.4in
Track - rear: 51.7in
Overall length: 179.8in
Overall width: 66in
Overall height: 55.7in
Ground clearance: 6.1in
Turning circle: 35.8 ft
Fuel tank: 15gals
Kerb weight: 25.5cwt
P6 Production
1963-76: 64,042 produced
Front: Independent coil, anti-roll bar
Rear: de Dion tube suspension
Wheels
5 stud, 16in pressed steel
6.50 x 14in radial tyres
Construction
Non-stressed steel outer panels bolted on unitary steel body with safety cage
Dimensions & Weight
Wheelbase: 103.3in
Track - front: 53.4in
Track - rear: 51.7in
Overall length: 179.8in
Overall width: 66in
Overall height: 55.7in
Ground clearance: 6.1in
Turning circle: 35.8 ft
Fuel tank: 15gals
Kerb weight: 25.5cwt
P6 Production
1963-76: 64,042 produced
