Volvo P1800ES 1972-73
See specifications below illustration
Page 094D
Volvo P1800ES 1972-73 specifications
Engine (B20F): 4 cylinder in-line, ohv, 2 valves per cylinder
Displacement: 1,986cc
Bore & stroke:
89mm x 80mm
Compression ratio: 8.7 to 1
Carburation: fuel injection
Power output: 112bhp at 6,000rpm
Maximum speed: 116mph
Acceleration: 0-60mph 1.3secs
OFC: 25mpg
Construction: Pressed steel monocoque
Transmission: RWD, 5 forward speed manual, with laycock overdrive, Borg Warner automatic an available option
Brakes: hydraulic PA, F: disc R: drum
Steering: cam & roller
Wheels: 15in, ventilated pressed steel
Suspension F&R: coil & wishbone, telescopic dampers with Panhard rod at rear
Wheelbase: 96.5in
Track F&R: 51.7in
Overall length: 172.6in
Overall width: 66.9in
Overall height: 50.4in
Ground clearance: 6.1in
Kerb weight: 2,570lb
Fuel tank: 10gal
1800ES production: 1972-73: 8,077 built.
Total production of P1800 variants 1961-73 : 47,492
