Ferrari Dino 246GT 1969-74
See specifications and an old advert below illustration
Page 215
Ferrari Dino 246GT 1969-74 specifications
Specifications

Engine: Mid, transverse, water cooled 2,418cc V-6 65º, cast iron block, Aluminium cylinder head

Bore & Stroke: 92.5mm x 60mm

Compression ratio: 9 to 1

Max power: 195bhp at 7,600rpm

Max torque: 225Nm/166ft lbs at 5,500rpm

Maximum speed: 141mph

Acceleration: 0-60mph 7.9secs

A.F.C.: 7.8km/L (22mpg)

Transmission: 5 speed ?manual, rear wheel drive

Steering: Rack and pinion

Brakes: Servo-assisted, ?front: 270mm disc, rear: 254mm disc

Suspension: Independent coil & double wishbone front & rear

Wheels: Bolt on 6.5J x 14 alloy

Tyres: 205/70 VR14

Construction: Pininfarina styled, steel body on steel tubular chassis

Dimensions

Wheelbase: 2,340mm

Track F: 1,427mm, R: 1,430mm

Overall length: 4,234mm

Overall width: 1,707mm

Overall height: 1,143mm 166.7in

Turning circle: 13.2m

Ground clearance: 120mm

Kerb weight: 1,257.6kg

Tank capacity: 70.4Litre 14.3 gal
