Fiat 500F 1965-73
See specifications below illustration
Page 229F
Fiat 500F 1965-73 specifications
Engine: air cooled two cylinder OHV
Capacity: 499cc
Bore: 67.4mm
Stroke: 70.00mm
Valves: 4, 2 per cylinder
Compression ratio: 7.1 to 1
Power: 18bhp at 4,600rpm
Max speed: 95km/h / 59mph
0-50mph/80.5kmh: 35.8secs
OFC: 18km/l / 48mpg
Transmission: RWD, manual 4 speed
Construction: pressed steel unitary
Suspension, front: tranverse leaf, rear: independent coil and wishbone, telescopic shock absorbers
Wheels: 12in pressed steel
Dimensions & Weight
Wheelbase: 1,842mm/72.5in
Length: 2,970mm/116.9in
Width: 1,320mm/52in
Height: 1,325mm/52in
Track front: 1,118mm/44in
Rear: 1,130mm/44.5in
Kerb weight: 523kg /1,130 lb
Fuel Tank: 20.9L/4.6 UKgal

Production: 1965-1972 with around 2,272 Mio biult
Total Fiat 500 built: 1957-75, approx 3.6 million produced
