Jaguar Mk2 340 1967-69
See specifications and old advertisment below illustration
Page 043B
Jaguar 340 1967-69 specifications
Engine
6 Cylinder in line
Bore: 83 mm
Stroke: 106 mm
Displacement: 3,442 cc
Valves: inclined o.h.v
Compression ratio: 9 to 1
Carburettors: two 13/4 HD6 SU
Power output: 220bhp at 5,500rpm

Performance
Maximum speed:119.9mph
Acceleration: 0-60 mph 10.5secs
Overall fuel consumption: 16mpg

Construction
Unitary all steel

Transmission
Manual 4 speed with Laycock de Normanville overdrive
Ratios: Top 3.54, 2nd 7.012, 3rd 4.541
1st and reverse 11.95 to one
Propellar Shaft: Hardy Spicer
Clutch: single dry plate 10in

Brakes
Servo assisted, discs all round
Front 11in disc, Rear 11.75in disc

Steering
Power assisted rack and pinion,
4.3 turns lock to lock
Turning circle: 36ft 9in(between kerbs)
30ft 8in(between walls)

Suspension
Front: Semi trailing wishbone & coil
Rear: Live axle on cantilever leaf, radius arms, Panhard rod & telescopic dampers

Wheels
Centre lock 15in wire x 5in rims
with 640 x 13 tubed radial tyres

Dimensions & Weight
Wheelbase: 8ft 11.4in
Track - front: 4ft 7in
Track - rear: 4ft 5.4in
Overall length: 15ft 0.75in
Overall width: 5ft 6.75in
Overall height: 4ft 9.5in
Ground clearance: 7in
Kerb weight: 29.9cwt
Weight distribution: front 56.5%,
rear 43.5%
Luggage space approx: 13cu ft
Petrol tank capacity: gallons
Oil: 13 pints, Cooling: 20 pints
