Morris Oxford Series VI Farina 1961-71
See specifications below illustration
Page 139C
Morris Oxford Series VI Farina Automatic 1961-71 specifications
Engine: “B’ Series, 4 cylinder in line, ohv, cast iron blaock and head, 3 main bearings
Bore & Stroke: 76.2mm x 88.9mm
Displacement: 1,622cc
Compression ratio: 8.3 to 1
Carburetors: single downdraft SU HS2
Power output: 61bhp at 4,350rpm
Torque: 90 lb/ft at 2,100rpm
Maximum speed: 84mph
Acceleration 0-60mph: 23.7secs
Overall fuel consumption: 26.7mpg
Transmission: RWD, 3 speed, Borg Warner automatic
Construction: Integral with steel body
Brakes: Girling hydraulic 9in drums
Steering: cam & peg, 3 turns lock to lock, 37ft 1in turning circle between curbs
Suspension front: ind. coil & wishbone
Suspension rear: semi-elliptic, leaf spring Anti-roll bars, Armstrong lever arm shock absorbers front & rear
Wheels: pressed steel disc, 4 studs, 5.90 x 14in crossply tyres
Dimensions
Wheelbase: 8ft 3.25in
Track: front 4ft 2in, ?rear: 4ft 0.25in
Overall length: 14ft 10in
Overall width: 5ft 3.75in
Overall height: 4ft 11.75in
Ground clearance: 7in
Kerb weight: 22.95cwt

Capacities
Fuel tank:10.5 gallons
Sump: 8 pints
Cooling system: 12pints

Morris Oxford VI Production
1961-71, Longbridge: 208,823
