Triumph TR6 1969-76 wire wheels
See specifications below illustration To TR2-8 page
Page 098B
Triumph TR6 1969-76 specifications
Engine
6 Cylinder in line
Displacement: 2,496cc
Bore: 74.7mm
Stroke:95mm
Valves: overhead, 12
Carburation: injection
Compression ratio: 9.5 to1
Power output: 142bhp at 5700rpm

Performance
Maximum speed: 121mph
Acceleration: 0-60 mph 8.2secs
Overall fuel consumption: 20mpg

Transmission
Clutch: Borg & Beck single
dry plate
Gearbox: 4-speed, manual overdrive
Construction
All metal body on ladder type chassis

Brakes
Hydraulic, power assisted
Front: disk
Rear: drums

Steering
Rack and pinion

Suspension
Front: independant coil and wishbones
Rear: independant, semi trailing arms, coil springs
Wheels
15in ventilated steel disc
Wire wheels as optional

Dimensions & Weight
Wheelbase: 7ft 4in
Track - front: 4ft 2.25in
Track - rear: 4ft 1.75in
Overall length:12ft 11in
Overall width: 4ft 10in
Overall height: 4ft 2in
Ground clearance: 6in
Kerb weight: 22.1cwt
Fuel tank capacity:111/4 gallons

Production
TR6: 1969-76 94,619
