See larger specifications below illustration
Page M22
Engine (99H)
4 cylinder in-line, 8 overhead valves
Displacement: 998cc
Bore & Stroke: 64.59mm x 76.2mm
Compression ratio: 8.3 to 1
Carburation: single SU HS2
Power output: 38bhp at 5,250rpm
Max Torque 52 lb/ft at 2,000rpm
Performance
Maximum speed: 75mph
0-60 mph: 26.2secs
Fuel consumption: 34mpg
Transmission
Front wheel drive
4-speed manual,
Brakes
Hydraulic, front & rear: drums
Steering
Rack & pinion
Suspension
Front & back: rubber cone,
hydraulic telescopic shock absorbers
4 cylinder in-line, 8 overhead valves
Displacement: 998cc
Bore & Stroke: 64.59mm x 76.2mm
Compression ratio: 8.3 to 1
Carburation: single SU HS2
Power output: 38bhp at 5,250rpm
Max Torque 52 lb/ft at 2,000rpm
Performance
Maximum speed: 75mph
0-60 mph: 26.2secs
Fuel consumption: 34mpg
Transmission
Front wheel drive
4-speed manual,
Brakes
Hydraulic, front & rear: drums
Steering
Rack & pinion
Suspension
Front & back: rubber cone,
hydraulic telescopic shock absorbers
Wheels
4 stud, 12in pressed steel
145/70SR12 tyres
Construction
Pressed steel monocoque
Dimensions & Weight
Wheelbase: 84.25in
Track front: 48.2in
Track front: 46.2in
Overall length: 120.25in
Overall width: 55.5in
Overall height: 53,5in
Ground clearance: 6in
Kerb weight: 13.25cwt
Fuel tank: 6.5gals
Morris Mini Traveller MK II Production
1967-1969 approx 23,500 built
Total production
(1959 - 2000) of all
Mini variants: 5,387,862
4 stud, 12in pressed steel
145/70SR12 tyres
Construction
Pressed steel monocoque
Dimensions & Weight
Wheelbase: 84.25in
Track front: 48.2in
Track front: 46.2in
Overall length: 120.25in
Overall width: 55.5in
Overall height: 53,5in
Ground clearance: 6in
Kerb weight: 13.25cwt
Fuel tank: 6.5gals
Morris Mini Traveller MK II Production
1967-1969 approx 23,500 built
Total production
(1959 - 2000) of all
Mini variants: 5,387,862
