Aston Martin DB7 Vantage 1993-2003 classic car portrait print

Engine: 60º V12, alloy block & head
Bore & stroke: 89mm x 79.5mm (3.5in x3.1in)
Displacement: 5,935cc (362.2in3)
Compression ratio: 10.3 to 1
Carburation: Multi Point Sequential Electronic Fuel Injection
Acceleration 0-60mph: 4.9secs
Max power: 420bhp (309KW) at 6,000 rpm
Maximum torque: 542Nm (400ft lb) at 5,000rpm
Maximum speed: 186mph (299.3km/h)
Construction: steel under-frame with steel and composite body panels
Fuel consumption: urban 16.6mpg, average 24.7mpg
Drag coefficient: 0.32
Transmission: RWD, 6-speed manual
Steering: rack and pinion, power-assisted, ?2.76 turns lock-to-lock
Turning circle: 11.6m
Suspension front: independent double wishbones & coil springs, anti-dive geometry, mono-tube dampers and anti-roll bar
Suspension rear: independent double wishbones, coil springs. longitudinal control arms and mono-tube dampers
Brakes: dual circuit, ABS, front: 285mm ventilated discs, rear: 295mm discs,
Wheels F/R: 8J x18”, 9J x18”, 10 spoke ?cast alloy
Tyres F/R: 245/40 R18, 265/35 R18
Wheelbase: 102in
Track front:- 60.5in, rear: 60.6in
Overall length: 184.75in
Overall width: 72.5in
Overall height: 49in
Ground clearance: 4.3in
Tank capacity: 19.6 Imp. gal
Kerb weight: 3,968.3 lb
Colour/Trim: Chiltern Green, Interior Tan and Forest with Walnut Wood trim
Production: 1999-2003, 1,477 built (approx 1/3 Manual)?Bloxham, Oxfordshire, England.
Styled by: Ian Callum and Keith Helfet.
Price at Launch: £92,500.00 in 1999.



			Aston Martin DB7 Vantage 1993-2003 See specifications below illustration . . To ASTON MARTIN page Page 193B Credit: assistance from Gareth Richards

			Aston Martin DB7 Vantage 1993-2003 specifications
			Engine: 60º V12, alloy block & head Bore & stroke: 89mm x 79.5mm (3.5in x3.1in) Displacement: 5,935cc (362.2in3) Compression ratio: 10.3 to 1 Carburation: Multi Point Sequential Electronic Fuel Injection Acceleration 0-60mph: 4.9secs Max power: 420bhp (309KW) at 6,000 rpm Maximum torque: 542Nm (400ft lb) at 5,000rpm Maximum speed: 186mph (299.3km/h) Construction: steel under-frame with steel and composite body panels Fuel consumption: urban 16.6mpg, average 24.7mpg Drag coefficient: 0.32 Transmission: RWD, 6-speed manual Steering: rack and pinion, power-assisted, ?2.76 turns lock-to-lock Turning circle: 11.6m Suspension front: independent double wishbones & coil springs, anti-dive geometry, mono-tube dampers and anti-roll bar Suspension rear: independent double wishbones, coil springs. longitudinal control arms and mono-tube dampers Brakes: dual circuit, ABS, front: 285mm ventilated discs, rear: 295mm discs, Wheels F/R: 8J x18”, 9J x18”, 10 spoke ?cast alloy Tyres F/R: 245/40 R18, 265/35 R18 Wheelbase: 102in Track front:- 60.5in, rear: 60.6in Overall length: 184.75in Overall width: 72.5in Overall height: 49in Ground clearance: 4.3in Tank capacity: 19.6 Imp. gal Kerb weight: 3,968.3 lb Colour/Trim: Chiltern Green, Interior Tan and Forest with Walnut Wood trim Production: 1999-2003, 1,477 built (approx 1/3 Manual)?Bloxham, Oxfordshire, England. Styled by: Ian Callum and Keith Helfet. Price at Launch: £92,500.00 in 1999.
