Aston Martin V12 Vanquish 2002-07
See specifications below illustration. To ASTON MARTIN page
Page 196
Aston Martin V12 Vanquish 2002-07 specifications
Engine: front mounted, all-alloy, quad overhead camshaft, 48 valve, front-position, V12 60º vee

Bore & Stroke: 88mm x 79.5mm (3.5in x 3.13in)

Displacement: 5,935cc (362.176in3) 494.58cc per cylinder

Compression Ratio: 10.5 to 1

Carburation: petrol, EFI

Acceleration: 0-100km/h 4.7secs (0-60mph: 4.4sec)

Max Power: 335kW (456PS/450bhp) at 6,500 rpm

Maximum Torque: 540Nm (400 lb-ft) at 5,000 rpm

Maximum Speed: 189.5mph (305km/h

Construction: extruded bonded aluminium VH structure, aluminium and composite body panels

Drag Coefficency: 0.33

Fuel Consumption: urban 8.5mpg, average 13.4mpg (UK gal)

Transmission: 6 speed automatic with electronic shift-by-wire control system, final drive ratio 3.69

Suspension Front: independent double wishbones & coil springs, anti-roll bar and monotube adaptive dampers. Rear: Independent double wishbones, coil springs with anti-squat and anti-lift geometry

 Brakes: dual circuit, ventilated 355mm(front), 330mm(rear) disc, ABS

Steering: rack and pinion VPAS, 2.73 turns lock-to-lock, 38.7ft turning circle

Wheels: 19” 15-spoke cast alloy silver painted wheels, front: 9J, rear : 10J

Tyres Front: 255/40 ZR19. Rear: 285/35 ZR19

Wheelbase: 105.9in

Track Front:- 60in, rear: 60.2in

Overall Length: 183.7in

Overall Width: 75.7in

Overall Height: 51.9in

Tank Capacity: 80 litres (17.6 Imp. gal)

Kerb Weight: 36.12cwt/1,835kg

Production: 2002-2007 - Newport Pagnell, Buckinghamshire, England
Designed by Ian Callum
