Corvette C4 1984-1996
See specifications and enlarged front view below illustration. e
Page 276
Corvette C4 1984-1996 specifications

Engine: Chevrolet V8, 90ºvee, OHV, 5 bearings, cast iron block & heads, water cooled
Bore: 99mm / 4.00in
Stroke: 92mm / 3.62in
Displacement: 5,733cc / 349.849cu in
Valves: Pushrod/overhead, 16in total
Compression ratio: 9.5 to 1
Carburation: Petrol, sequential fuel injection
Power output: 205bhp at 4,300rpm
Maximum torque: 290 ft/lb at 2,800rpm
Maximum speed: 170mph
Acceleration: 0-60mph 6.2secs
A.F.C.: 21,5mpg, 17.9mpg US, 13.1 litres/100km
Suspension Front: independent unequal length double wishbones Rear: fibre gass transverse mono leaf springs
Construction: grp body on steel chassis
Brakes: Hydraulic, discs front & rear
Steering: Power assisted rack and pinion
Transmission: 4 speed automatic, rear wheel drive, limited slip diff.
Axle ratio: 3.08 to 1
Wheels: 15in pressed steel, F70-15 tyres front & rear


Wheelbase: 96.2in / 2,443mm
Track - front: 59.6in / 1,513mm
Track - rear: 60.4in / 1,534mm
Overall length: 176.5in / 4,483mm
Overall width: 71in / 1,804mm
Overall height: 46.7in / 1,186mm
Kerb weight: 3,330 lb / 1,435kg


1984-1996: 358,180
Coupe: 276,590
Convertible: 74,651
ZR1: 6,939Bowling Green, Kentucky,USA
