Lotus Esprit S4s 1995-96
below illustration
Page 207CSee specifications
Lotus Esprit S4s 1995-96 specifications
Engine: longitudinallly mid mounted, ?all alluminium, 4 in-line,16 valve, ?Hybrid T3/T60 turbocharger

Capacity: 2,174cc

Bore & stroke: 95.3mm x 76.2mm

Compresion ratio: 8.0 to1

Carburation: petrol, EFI

Power Output: 300bhp (224Kw) ?at 6,400rpm, Max torque 290 lb ft ?at 4,100rpm
Max Speed: 168mph

0-60 mph: 4.9sec

Fuel Consumption: urban: 18.8mpg, 56mph: 34.5, 75mph: 27.3

Transmission: high torque 5-speed transaxle, hydraulic clutch, RWD

Suspension F: independent double wishbone and coil

Suspension R: independent upper & lower transverse links with radious arms, coil springs, telescopic dampers

Brakes: dual circuit, Delco ABS F: 11.6in ventilated disc ?R: 11.8in ventilated disc

Steering: Rack and pinion, PAS

Wheels: OZ Racing 5 spoke alloy. ?F: 18"x8.5J, R: 18"x 10J

Tyres: F: 235/40ZR 17 R: 285/35zr 18

Construction: Glassfibre-reinforced plastic body with galvanised steel backbone chassis

Fuel Tank: 16gal

Length: 173.8in

Width: 74.1in

Height: 45.3in

Wheelbase: 95.3in

Track F & R: 59.8in

Weight: 2,970 lb

S4s Production: 1994-97: 367 Designed by Julian Thompson
List Price: £52,995
