Lotus Esprit Turbo 1987-90
See specifications below illustration
Page 207B
Lotus Esprit Turbo 1987-90 specifications
Engine: longitudinallly mid mounted, ?all alluminium, 4 in-line,16 valve, ?Garret T3 turbocharger

Capacity: 2,174cc

Bore & stroke: 95.3mm x 76.2mm

Compresion ratio: 8.0 to1

Carburettors: Twin Dellorto DHLA

Power Output: 215bhp(160Kw ISO) at 6,000rpm, ?Max torque 220 lb ft (298Nm) at 4,250rpm

Max Speed: 153.5mph

0-60 mph: 5.4sec

O.F.C.: 19.6mpg

Transmission: high torque 5-speed manual, hydraulic clutch, RWD

Suspension F: independent double wishbone & coil springs, anti roll bar, telescopic dampers

Suspension R: independent upper & lower transverse links with radious arms, coil springs, telescopic dampers, anti roll bar

Brakes: dual circuit, vacuum servo F: 10.1in ventilated disc ?R: 10.8in ventilated disc

Steering: Rack and pinion

Wheels: Lotus alloy. F: 15"x 7J, R: 16"x 8.5J

Tyres, F: 215/50ZR 15 R: 245/50 ZR 16

Construction: Glassfibre-reinforced plastic body with galvanised steel backbone chassis

Fuel Tank: 18gal

Length: 4,330mm

Width: 1,860mm

Height: 1,150mm

Wheelbase: 2,420mm

Track F/R: 1,524mm / 1555mm

Kerb Weight: 1,386Kg

Esprit Turbo Production: 1987-91 ?Designed by Peter Stevens

List Price: £33,765
