MG TF85 Limited Edition
See specifications below illustration
Page 223C
MG TF LE85 Specifications
Engine: N Series 16v inline DOHC, mid mounted
Bore & Stroke: 80mm x 89.3mm
Displacement: 1,796cc
Compression ratio: 10.5 to1
Carburation: programmed injection
Max power: 134bhp at 6,750rpm
Torque: 165Nm/16.8kgm at 5,000rpm
Maximum speed: 127mph
Acceleration: 0-60mph 8.4secs
Overall fuel consumption: 35.6mpg
Transmission: 5-speed, manual, RWD
Clutch: single dry-plate diaphragm
Body/Chassis: Monocoque steel construction, 2 seat convertible
Cd: 0.36
Steering: Rack and pinion, power assisted 2.81 turns lock to lock
Brakes: Front: 12in ventilated disc, Rear: 9.4in solid disc, Bosch type ABS
Suspension: Front: Double wishbone coil spring, Rear: multilink with coil springs spring, gas filled telescopic dampers all round
Eibach Sports anti-roll bar
Wheels & Tyres: 16in “twist of pepper” bolt on alloy with 195/45 ZR16(front) and
215/40 ZR16(rear) low profile tyres
Colours, body: Intense Cassis, Aubergine upholstery

Wheelbase: 93.8in
Track, front: 55.2in, rear: 55.5in
Overall length: 155.2in
Overall width: 71.32in
Height: 49.65in
Ground clearance: 5in
Turning circle: 34.7ft
Tank capacity: 11gals
Weight: 1,150kg

Production: Total TF 85 built: 50
Price new MG TF 85 in 2009: £15,664
Total Rover built: MG TF 2002-2005 41,635 built, Longbridge, Birmingham
after-marhket rear lights version available:
