MG ZS 180 2001-05
See specifications below illustration
Page 269
MG ZS 180 2001-05 Specifications
Engine (KV6): 6 cylinder, DOHC, transverse, frontal position
Displacement: 2,497cc
Bore & Stroke: 80mm x 82.8mm
Compression ratio: 10.5 to1
Max power: 174bhp at 6,500rpm
Carburation: petrol, Siemens EMS2000 Multipoint injection
Maximum speed: 139mph
Acceleration 0-60 mph: 7.3secs
Overall fuel consumption: 33.2mpg
Transmission: front wheel drive, 5-speed, manual, single dry-plate diaphragm clutch
Gear ratios top: 0.77, final drive: 3.94
Body/Chassis: Monocoque steel construction
Steering: Rack and pinion, power assisted
Brakes front: 282mm ventilated disc, rear: 260 ventilated disc with ABS
Suspension front: independent double wishbone & coil, anti-roll bar rear: independent, multi link, coil, anti-roll bar
Wheels & Tyres: 7J x 17in alloy with 205/45 R17 tyres

Wheelbase: 103.1in / 2,746mm
Track front: 58.1in / 1,475mm rear: 57.7in / 1,465mm
Length: 172.3in / 4,377mm
Width: 66.8in / 1,696mm
Height: 54.6in / 1,286mm
Tank capacity: 12.1gals / 55L
Weight: 2,833 lb / 1,285kg

MG ZS 180: 2001-2005
6,876 built, MG Rover, Longbridge
Birmingham, England
