See specifications below illustration
Page 063
Engine
Engine Four cylinder Ford Zetec. 1798cc. 80.6 mm bore x 88.0 mm stroke. Double overhead camshaft.
16 valves with hydraulic tappets.
Fuel injected.
10:1 compression ratio.
121 bhp at 5750 rpm.
Performance
0 to 60 mph in 8.9 seconds. Top speed 118 mph. Power to weight ratio 165 hp per ton.
Chassis
Deep Z-shaped steel section with five boxed or tubular cross members.
Gearbox
Five speed and reverse Ford gearbox.. Synchromesh on all forward gears.
Engine Four cylinder Ford Zetec. 1798cc. 80.6 mm bore x 88.0 mm stroke. Double overhead camshaft.
16 valves with hydraulic tappets.
Fuel injected.
10:1 compression ratio.
121 bhp at 5750 rpm.
Performance
0 to 60 mph in 8.9 seconds. Top speed 118 mph. Power to weight ratio 165 hp per ton.
Chassis
Deep Z-shaped steel section with five boxed or tubular cross members.
Gearbox
Five speed and reverse Ford gearbox.. Synchromesh on all forward gears.
Brakes
Hydraulic dual brake system with vacuum servo assistance. AP Lockheed 4 pot callipers acting on
11" diameter discs on front wheels.
9 " x 1.75 "drum brakes on rear.
Fly-off hand brake.
Steering
Rack and pinion. Three turns lock to lock. Turning circle 32 feet.
Suspension
Front wheels are independently sprung by patented Morgan ‘sliding pillar’suspension with vertical coil springs. Semi-elliptical rear springs. Gas filled telescopic shock absorbers at front and rear.
Hydraulic dual brake system with vacuum servo assistance. AP Lockheed 4 pot callipers acting on
11" diameter discs on front wheels.
9 " x 1.75 "drum brakes on rear.
Fly-off hand brake.
Steering
Rack and pinion. Three turns lock to lock. Turning circle 32 feet.
Suspension
Front wheels are independently sprung by patented Morgan ‘sliding pillar’suspension with vertical coil springs. Semi-elliptical rear springs. Gas filled telescopic shock absorbers at front and rear.
Wheels
Centre lock chromed wire wheels on Rudge hubs with 6" wide rims.
195 60 VR15 tyres.
Bodywork
Aluminium panels.
Ash hardwood frame treated
with Cuprinol.
Zinc plated fittings.
Connolly leather upholstery.
Reclining seats at front.
Rear seats fold forward to give luggage space.
Walnut dashboard.
Fuel Consumption
Combined urban/motorway: 37 mpg
Dimensions & Weight
Wheelbase: 8ft
Track - front: 4ft
Track - rear: 4ft 1in
Overall length: 13ft 2in
Overall width: 4ft 11in
Overall height: 4ft 4in
Ground Clearance: 5in
Kerb weight: 2,140 lbs
Fuel tank capacity: 12 gals
Aluminium panels.
Ash hardwood frame treated
with Cuprinol.
Zinc plated fittings.
Connolly leather upholstery.
Reclining seats at front.
Rear seats fold forward to give luggage space.
Walnut dashboard.
Fuel Consumption
Combined urban/motorway: 37 mpg
Dimensions & Weight
Wheelbase: 8ft
Track - front: 4ft
Track - rear: 4ft 1in
Overall length: 13ft 2in
Overall width: 4ft 11in
Overall height: 4ft 4in
Ground Clearance: 5in
Kerb weight: 2,140 lbs
Fuel tank capacity: 12 gals
