Porsche Boxster 987 2004-11
See specifications below illustration
Page 190B
Porsche Boxster 987 2004-11 specifications
Engine (Tiptronic S VarioCam Plus): All aluminium, 6 Cylinder, horizontally mounted, 24 valves, 4 per cylinder, variable double OHC

Bore & stroke: 85.5mm x 78.0mm

Displacement: 2,687cc, 447.8cc per cylinder

Compression ratio: 11.0 to 1

Maximum speed: 250km/h (160mph)

Acceleration: 0-100km/h 7.10secs (0-60mph 6.1sec)

Max power: 180kw at 6,400rpm

Max torque: 272Nm at 4,400rpm

Construction: pressed steel monocoque

Fuel consumption: urban 14.91 /100km (19mpg), ?average: 10.1 l/100 km(28mpg), CO2: 242 grams/km

Transmission: PDK (Porsche Doppelkupplung) 7 speed manual, rear engined, rear wheel drive, final drive ratio 3.56

Brakes front & rear: Dual circuit, ventilated disc, ABS

Suspension: Coil McPherson Strut front & rear, ?Panhard at rear

Steering: PA rack & pinion

Wheels: Aluminium bolt-on 5 stud, 7J x 17 front, 8.5J at rear

Tyres front: 205/55 R17, rear: 255/50 R17

Wheelbase: 2,416mm

Track front: 1,490mm, rear: 1.534mm

Overall length: 4,328mm

Overall width: 1,801mm

Overall height: 1,290mm

Ground clearance: 127mm

Tank capacity: 64 litres (14.1 UK gal)

Unladen weight: 1,335kg

Production: Stuttgart, Germany and Uusikaupunki, Finland 1996-present, designed by Harm Lagaay
