See specifications below illustration
Page 171
Engine: All alloy V8, OHV, 5 main bearings (cross-bolted)
Bore & stroke: 94.04mm x 82.0mm
Displacement: 4,600cc
Valves: overhead, 16, hydraulic lifters
Compression ratio: 9.75 to 1
Carburation: Fuel Injection Bosch/Lucas L-Jetronic
0-60mph: approx 7.0secs
Approx fuel consumption: 24mpg (average)
Transmission: 5-speed Tremec T5. Quaife LSD
Brakes: PA. F: Discs 284mm (Jaguar XJ-S) R: Standard drums
Steering: Rack and pinion, 2.75 turns lock to lock
Suspension F: Independent multi-sequential Coil, R: live axle, coil, double wishbone and trailing link
Wheels: Revolution 5-spoke 15 x 8 ?with 215/60R15 tyres
Construction: pressed steel monocoque
Wheelbase: 110.8in
Track: - front: 59.1in, rear: 59.3in
Overall length: 186in
Overall width: 69.6in
Overall height: 54.5in
Turning circle: 34ft 1in
Fuel tank: 14.5 Imp gals
Kerb weight: 27.5cwt
SD1 Production
1976-85: 303,345 produced
Vitesse 1982-86 price at launch £14.950
Designer: David Bache
