See specifications and old advertisment below illustration
Page 115B
Steering
Cam gears,cam & peg,
3 turns lock to lock
Turning circle: 34ft 9in
Suspension
Front: Independent coil & wishbone
Rear: semi-elliptic, leaf spring
Anti-roll bars, Armstrong lever arm shock absorbers front & rear
Wheels
Pressed steel 4 studs
5.90 x 14in crossply tyres
Dimensions & Weight
Wheelbase: 8ft 31/4in
Track - front: 4ft 2in
Track - rear: 4ft 01/2in
Overall length: 14ft 10in
Overall width: 5ft 33/4in
Overall height: 4ft 113/4in
Ground clearance: 7in
Kerb weight: 21.63cwt
Capacities
Fuel tank :101/2gallons
Sump: 8pints
Cooling system: 12pints
A60 Farina Production
1959-61: 276,534, Longbridge then at Cowley after 1964
Cam gears,cam & peg,
3 turns lock to lock
Turning circle: 34ft 9in
Suspension
Front: Independent coil & wishbone
Rear: semi-elliptic, leaf spring
Anti-roll bars, Armstrong lever arm shock absorbers front & rear
Wheels
Pressed steel 4 studs
5.90 x 14in crossply tyres
Dimensions & Weight
Wheelbase: 8ft 31/4in
Track - front: 4ft 2in
Track - rear: 4ft 01/2in
Overall length: 14ft 10in
Overall width: 5ft 33/4in
Overall height: 4ft 113/4in
Ground clearance: 7in
Kerb weight: 21.63cwt
Capacities
Fuel tank :101/2gallons
Sump: 8pints
Cooling system: 12pints
A60 Farina Production
1959-61: 276,534, Longbridge then at Cowley after 1964
Engine
4 Cylinder in line
Bore: 76.2mm
Stroke: 88.9mm
Displacement: 1,622cc
Valves: pushrod overhead
Compression ratio: 8:3 to 1
Carburettors: single
downdraught SU
Power output: 61bhp at 4,350rpm
Torque: 90 lb/ft at 2,100rpm
Performance
Maximum speed: 84mph
Acceleration: 0-60mph 21.4secs
Overall fuel consumption: 26.2mpg
Transmission
Clutch: Borg & Beck single dry
plate, 8in diam
Gearbox: 4 speed, synchromesh
on 2nd, 3rd and top gears
Ratios: Top 4.3, 3rd 5.91,
2nd 9.52,
1st 15.64, reverse 20.45 Final drive: Hypoid bevel' 4.3 to 1
Construction
Steel bodied monocoque
Brakes
Girling hydraulic 9in drums
4 Cylinder in line
Bore: 76.2mm
Stroke: 88.9mm
Displacement: 1,622cc
Valves: pushrod overhead
Compression ratio: 8:3 to 1
Carburettors: single
downdraught SU
Power output: 61bhp at 4,350rpm
Torque: 90 lb/ft at 2,100rpm
Performance
Maximum speed: 84mph
Acceleration: 0-60mph 21.4secs
Overall fuel consumption: 26.2mpg
Transmission
Clutch: Borg & Beck single dry
plate, 8in diam
Gearbox: 4 speed, synchromesh
on 2nd, 3rd and top gears
Ratios: Top 4.3, 3rd 5.91,
2nd 9.52,
1st 15.64, reverse 20.45 Final drive: Hypoid bevel' 4.3 to 1
Construction
Steel bodied monocoque
Brakes
Girling hydraulic 9in drums
