Ford Consul Capri 1961-62
See specifications and old advertisment below illustration
Page 024A • Ford Classic & Capri Owners Club
Ford Consul Capri 1961-62 Specifications
4 cylinder in-line, OHV
Displacement: 1,340cc
Bore: 81.00mm
Stroke: 65.1 mm
Valves: 2 per cylinder
Carburation: single Zenith downdraught
Compression ratio 8.5 : 1
Power output: 54bhp at 4,900rpm

Maximum speed: 82mph
Acceleration: 0-60mph 21.3
Overall fuel
consumption approx: 27.9mpg

Recirculating ball

4 speed manual with synchromesh on 2nd, 3rd and top.
Hydraulic 8in clutch
Rear wheel drive
Final drive: hypoid bevel

Hydraulic, front: disc
rear: 9in drums

Pressed steel monocoque

Front: Independent MacPherson strut, anti-roll bar
Rear: Semi-elliptic leaf springs

4 stud, 13in pressed steel
5.90 x 13 tyres

Dimensions & Weight
Wheelbase: 8ft 3in
Front track: 4ft 0.5in
Rear track: 4ft 0.5in
Overall length: 14ft 2.8in
Overall width: 5ft 5.2in
Overall height: 4ft 6in
Kerb weight: 18.39cwt
Ground clearance: 6in

Consul Capri Production
1340cc 1961-62: 11,143
Std 1500cc 1962-63: 5,571
GTs 1963-64: 2,002
Total 1500cc/GTs: 7,573
