See specifications below illustration
Page 018C
Engine
90 degree V8, ohv
Bore: 76.2mm Stroke: 69.85 mm
Displacement: 2,547cc
Carburettors: twin SU
Power output: 140 bhp at 5,500rpm
Torque: 155lb ft at 3,600rpm
Performance
Maximum speed: 123mph
Acceleration: 0-60 mph 8.9 secs
Overall fuel consumption: 25.5 mpg
Construction
Resin-bonded glass fibre body on ladder-frame steel chassis
90 degree V8, ohv
Bore: 76.2mm Stroke: 69.85 mm
Displacement: 2,547cc
Carburettors: twin SU
Power output: 140 bhp at 5,500rpm
Torque: 155lb ft at 3,600rpm
Performance
Maximum speed: 123mph
Acceleration: 0-60 mph 8.9 secs
Overall fuel consumption: 25.5 mpg
Construction
Resin-bonded glass fibre body on ladder-frame steel chassis
Transmission
4-speed manual plus overdrive
Brakes
Girling hyraulic, discs all round
Steering
Worm and peg
Suspension
Front: Independent with wishbones and coil springs
Rear: Live axle with leaf springs
Wheels
Ventilated pressed steel disc or
knock-on wire wheels(optional)
4-speed manual plus overdrive
Brakes
Girling hyraulic, discs all round
Steering
Worm and peg
Suspension
Front: Independent with wishbones and coil springs
Rear: Live axle with leaf springs
Wheels
Ventilated pressed steel disc or
knock-on wire wheels(optional)
Dimensions & Weight
Wheelbase: 7ft 10in
Track - front: 4ft 2.5in
Track - rear: 4ft
Overall length: 13ft 4.5in
Overall width: 5ft 0.5in
Overall height: 3ft 6in
Kerb weight: 18.48cwt
Production
1959-64 2,644
Wheelbase: 7ft 10in
Track - front: 4ft 2.5in
Track - rear: 4ft
Overall length: 13ft 4.5in
Overall width: 5ft 0.5in
Overall height: 3ft 6in
Kerb weight: 18.48cwt
Production
1959-64 2,644
