Jaguar E-Type Roadster Series 2 1969-72
See specifications below illustration
Page 041G
Jaguar E-Type Roadster Series 2 1969-72 specifications
Engine: 6 Cylinder in line, dohc
Bore & Stroke: 92mm x 106mm
Displacement: 4,235cc
Compression ratio: 9 to1
Valves: 2 per cylinder
Carburettors: 3 x 2in SU HD8
Power output: 265bhp at 5,500rpm
Maximum speed: 141mph
0-60mph: 7.0secs
AFC: 21.8mpg
Transmission: RWD, 4-speed manual, syncromesh on top 3 ratios, Borg-Warner automatic option
Construction: Steel monocoque with square tube subframe at front, pressed steel subframe at rear
Brakes: discs all round, inboard mounted at rear, servo assisted
Steering: rack and pinion,
Suspension F: Independent with torsion bars, wishbones, anti roll bar
Suspension R: Independent, double spring/shock units, tranverse lower links, longitudinal radius arms Wheels: knock-on 15 in wire with 6.40 x 15 RS5 crossply tyres
Wheelbase: 8ft
Track - F: 4ft 2in, R: 4ft 2in
Overall length: 14ft 7.3in
Overall width: 5ft 5.3in
Overall height: 4ft
Turning circle: 37ft
Kerb weight: 24.55cwt
Production: 1969-72 FHC: 4,855 OTS: 8,628 2+2: 5,326 Total of all SII: 18,809
