See specifications and rally photo (Eastbourne) below illustration.To FORDS page
Page 020b
below: Magnificent Motors,
Eastbourne 2007
Eastbourne 2007
Engine
4 cylinder in-line,
Valves: side, 8
Displacement: 1,172cc
Bore: 63.5mm
Stroke: 92.56mm
Compression ratio: 6.3 - 1
Valves (side): 2 per cylinder
Carburettors: one
Power output: 30bhp at 4,000rpm
Performance
Maximum speed: 60mph
Acceleration: 0-50 mph 38.2secs
Overall fuel consumption: 36mpg
4 cylinder in-line,
Valves: side, 8
Displacement: 1,172cc
Bore: 63.5mm
Stroke: 92.56mm
Compression ratio: 6.3 - 1
Valves (side): 2 per cylinder
Carburettors: one
Power output: 30bhp at 4,000rpm
Performance
Maximum speed: 60mph
Acceleration: 0-50 mph 38.2secs
Overall fuel consumption: 36mpg
Transmission
3 forward speed manual
Rear wheel drive
Construction
Pressed steel body on
steel channel chassis
Brakes
Hyraulic, drum all round
Suspension
Front & Rear: Semi-elliptic leaf springs
Steering
Rack and pinion
Wheels
17in, pressed steel
Dimensions & Weight
Wheelbase: 7ft 6in
Track F: 3ft 7in
Track R: 3ft 7in
Overall length: 12ft 8.2in
Overall width:4ft 7.9in
Overall height: 5ft 4.2in
Ground clearance: 8.8in
Kerb weight: 1,687lbs
Fuel tank 8.4gals
Production
1953-1959
UK production: 148,020
World total: 580,564
basic price in 1953: £390
Front & Rear: Semi-elliptic leaf springs
Steering
Rack and pinion
Wheels
17in, pressed steel
Dimensions & Weight
Wheelbase: 7ft 6in
Track F: 3ft 7in
Track R: 3ft 7in
Overall length: 12ft 8.2in
Overall width:4ft 7.9in
Overall height: 5ft 4.2in
Ground clearance: 8.8in
Kerb weight: 1,687lbs
Fuel tank 8.4gals
Production
1953-1959
UK production: 148,020
World total: 580,564
basic price in 1953: £390
