Note: this example depicts the earlier smooth finished hardtop now rare because of it weaknesses
See specifications below illustration. To HERALD & VITESSE page.
Page 087F
Engine
4 Cylinder in line
Bore: 63mm, Stroke: 76mm
Displacement: 948cc
Compression ratio: 8.5/1
Carburettors: twin SU H2
Power output: 50.5bhp at 6,000rpm
Torque: 48 lbft at 2,750rpm
Performance
Maximum speed: 71.5mph
Acceleration: 0-60 mph 30.4secs
Overall fuel consumption: 32.4mpg
Construction
Steel body & panels bolted onto steel backbone frame
Transmission
Clutch: 6.25in single dry plate
Gearbox: 4-speed, synchromesh on
top 3 gears
Ratios: Top 4.45, 3rd 6.62, 2nd 11.2, 1st & reverse 19.45
Differential ratio: 4.55
Wheels
Bolt-on 13in Pressed steel disc
Rims: 31/2D, tyres: 520 x 13in
Brakes
Girling hydraulic drums front and rear
4 Cylinder in line
Bore: 63mm, Stroke: 76mm
Displacement: 948cc
Compression ratio: 8.5/1
Carburettors: twin SU H2
Power output: 50.5bhp at 6,000rpm
Torque: 48 lbft at 2,750rpm
Performance
Maximum speed: 71.5mph
Acceleration: 0-60 mph 30.4secs
Overall fuel consumption: 32.4mpg
Construction
Steel body & panels bolted onto steel backbone frame
Transmission
Clutch: 6.25in single dry plate
Gearbox: 4-speed, synchromesh on
top 3 gears
Ratios: Top 4.45, 3rd 6.62, 2nd 11.2, 1st & reverse 19.45
Differential ratio: 4.55
Wheels
Bolt-on 13in Pressed steel disc
Rims: 31/2D, tyres: 520 x 13in
Brakes
Girling hydraulic drums front and rear
Steering
Rack and pinion
Turning circle: 24ft
Suspension
Front: Independant coil and wishbone with telescopic hydraulic dampers, anti-roll bar, rear: independent with transverse leaf spring
Dimensions & Weight
Wheelbase: 7ft 8in
Track - front: 4ft 1in
Track - rear: 4ft
Overall length: 12ft 9in
Overall width: 5ft
Overall height: 4ft 4in
Dry weight: 15.75cwt
Capacities
Fuel Tank: 6.5gals
Engine: 8 pints
Cooling: 8.5 pints
Herald Coupé 948cc Production
1959-61: 23,426 produced.
Total Herald production
1959-71: 289,575
