Triumph Herald Convertible 13/60 1967-71
See specifications below illustration. To HERALD & VITESSE page.
Page 087K
Triumph Herald Convertible 13/60 1967-71 Specifications
4 Cylinder in line
Bore: 73.66mm
Stroke: 76mm
Displacement: 1,296cc
Compression ratio: 8.7:1
Carburettors: single Stromberg 150CD
Power output: (H)91bhp at 5,000rpm
(L)54 at 5500rpm
max Torque (H)875 (L)800 lb/in at 3,000rpm

Maximum speed approx: 85mph
Acceleration: 0-60 mph 16.6secs
Overall fuel consumption: 25mpg

Steel body & panels bolted on to steel backbone frame

Hydraulic, front: discs, rear: drums

Clutch: 8.25in Borg & Beck
Gearbox: 4-speed, synchromesh on
top 3 gears
Ratios (overall): Top 4.11, 3rd 5.74, 2nd 2.16, 1st & reverse 15.42
Rack and pinion
4.4 turns lock to lock
Turning circle: 25ft
Camber angle 2º positive

Front: Independant coil and wishbone anti-roll bar, rear: independent with transverse leaf spring
Telescopic dampers F&R

Wheels & Tyres
Bolt-on 13in 3.5D pressed steel
Tyres: 520 x13

Dimensions & Weight
Wheelbase: 7ft 8.5in
Track - front: 4ft
Track - rear: 4ft
Overall length: 12ft 9in
Overall width: 5ft
Overall height: 4ft 4in
Dry weight: 17.25cwt

Fuel Tank: 8.75gals
Engine: 8 pints
Cooling: 11 pints
Rear axle: 1 pint

13/60 Herald Production
Total Herald production 1959-71: 289,575
