Sunbeam Alpine Series IV 1964-65
See specifications below illustration
Page 083D
Whilst the trademark owner has consented to the reproduction of its logo and emblems it has no connection with or responsibility for this drawing or for the technical data and gives no warranty as to its accuracy.

Sunbeam Alpine Series IV 1964-65 specifications

Engine: 4 cylinder in-line, ohv, ?3 main bearings, iron block, alloy head
Displacement: 1,592cc
Bore & stroke: 81.5mm x 76.2mm
Compression ratio: 9.1 to 1
Carburettor: single Solex
Power output: 82bhp at 5,200rpm
Maximum torque: 94lb at 3,800rpm
Maximum speed: 98mph
Acceleration 0-60mph: 16.5secs
Overall fuel consumption: 30-35mpg
Transmission: RWD, 4-speed manual,
Construction: pressed steel monocoque reinforced underneath with a box-like structure similar to Hillman Husky
Brakes: hydraulic, front: disc, rear: drum
Steering: recirculating ball
Suspension front: ind. coil & wishbone, rear: Semi-elleptic leaf, telescopic dampers (series I & II lever arm)
Wheels: 4 stud, 13in, pressed steel disc or knock-on optional wire
Wheelbase: 86in
Track front:
Track rear: 48.5in
Overall length: 155.3in
Overall width: 60.5in
Overall height: 51.5in
Ground Clearance: 4.3in
Kerb weight:
Fuel tank: 11 Imp. gals ?(13.5 US)

Sunbeam Alpine Production 1959-68
Total production of Mk I, II, III, IV & V: 69,251
Mk IV (1964-65): 12,406
