Sunbeam Talbot 90 MkIIA 1952-54
See specifications below illustration
Page 082C
Whilst the trademark owner has consented to the reproduction of its logo and emblems it has no connection with or responsibility for this drawing or for the technical data and gives no warranty as to its accuracy.

Sunbeam Talbot 90 MkIIA 1952-54 specifications

4 Cylinder inline, ohv
Bore: 81mm
Stroke: 110mm
Displacement: 2,267cc
Compression ratio: 6.4:1
Carburettor: twin choke downdraught
Power output: 77bhp at 4,100rpm.

Maximum speed: 83mph
Acceleration: 0-60 mph 20.8 secs
Approx fuel consumption: 28mpg

Steel body on box section steel frame

4-speed manual, syncromesh on top 3 ratios, Laycock de Normanville overdrive
Ratios: 3.28(OD), 4.22(direct), 5.55, 9.14, and 11.81 to 1. Open prop shaft. Hypoid rear axle

Lockeed hydraulic, drums

Front: Beam axle together with semi-eliptic cart springs, Rear: semi elliptic leaf with Panhard rod, Armstrong hydraulic dampers all round

Wheels & Tyres
wheels with 16in x 5.50 crossply tyres

Dimensions & Weight
Wheelbase: 8ft 1.5in
Track - front: 3ft 11.5in
Track - rear: 4ft 2in
Overall length: 13ft 11.5in
Overall width: 5ft 2.5in
Height: 5ft 0.7in
Ground Clearance: 6.6in
Turning circle: 36ft
Kerb weight: 23.1cwt

Sunbeam Talbot 90 Production
MK II: 1950-1952 5,493 produced
MK IIA: 1952-1954 16,387 produced
