Sunbeam Talbot 90 MkI 1948-50
See specifications below illustration
Page 082B
Whilst the trademark owner has consented to the reproduction of its logo and emblems it has no connection with or responsibility for this drawing or for the technical data and gives no warranty as to its accuracy.

Sunbeam Talbot 90 MkI 1948-50 specifications

4 Cylinder inline, sidevalve
Bore: 75mm
Stroke: 110mm
Displacement: 1,944cc
Compression ratio: 6.6 to 1
Carburettor: single downdraught
Power output: 64bhp at 4,100rpm.

Maximum speed: 80mph
Acceleration 0-60mph: 26.8 secs
Approx fuel consumption: 28mpg

Steel body on box section steel frame
4-speed manual, syncromesh on top 3 ratios, Laycock de Normanville overdrive
Ratios: 3.28(OD), 4.22(direct), 5.55, 9.14, and 11.81 to 1. Open prop shaft. Hypoid rear axle

Lockeed hydraulic, drums

Front: Beam axle together with semi-eliptic cart springs, Rear: semi elliptic leaf with Panhard rod, Armstrong hydraulic dampers all round
Wheels & Tyres
16in bolt-on steel disc wheels with 16in x 5.50 crossply tyres

Dimensions & Weight
Wheelbase: 8ft 1.5in
Track - front: 3ft 11.5in
Track - rear: 4ft 2in
Overall length: 13ft 11.5in
Overall width: 5ft 2.5in
Height: 5ft 0.7in
Ground Clearance: 6.6in
Turning circle: 36ft
Kerb weight: 25.25cwt

Sunbeam Talbot Mk1 Production
MkI 80s: 3,500 produced
MKI 90s: 4,000 produced
