Wolseley 16/60 1961-71
See specifications below illustration
Page 219
Wolseley 16/60 1961-71 specifications
“B’ Series, 4 cylinder in line, ohv, cast iron blaock and head, 3 main bearings
Bore & Stroke: 76.2mm x 88.9mm
Displacement: 1,622cc
Compression ratio: 8.3 to 1
Carburetors: single semi-downdraft SU
Power output: 61bhp at 4,600rpm
Maximum speed: 86.5mph
Acceleration: 0-60mph 19.5secs
Overall fuel consumption: 38.3mpg
Transmission: RWD, 4 speed, synchromesh on 2nd, 3rd and top gears or optional 3 speed automatic
Construction: Integral with steel body
Brakes: Girling hydraulic 9in drums
Steering: cam & peg, 3 turns lock to lock, 34ft 9in turning circle
Suspension front: ind. coil & wishbone
Suspension rear: semi-elliptic, leaf spring Anti-roll bars, Armstrong lever arm shock absorbers front & rear
Wheels: pressed steel disc, 4 studs, 5.90 x 14in crossply tyres

Dimensions & Weight
Wheelbase: 8ft 4.25in
Track: front 4ft 2.6in, rear: 4ft 1.4in
Overall length: 14ft 10in
Overall width: 5ft 3.5in
Overall height: 4ft 10.8in
Ground clearance: 5.9in
Kerb weight: 22cwt

Fuel tank:10 Imp gal / 12 US gal
Sump: 8 pints
Cooling system: 12pints

1961-1971 63,082 built
