Ford Cortina Lotus Mk2 1967-70
See specifications below illustration
Page 031E
Ford Cortina Lotus Mk2 1967-70 Specifications
Engine: Lotus Cosworth 4 Cylinder, twin OHC

Displacement: 1,558cc

Bore & stroke: 82.5mm x 72.75mm

Compression ratio: 10.1 to 1

Carburation: Weber 40DC)E

Power output: 108bhp at 6,000rpm

Maximum speed: NA?mph

Acceleration 0-60mph: 11secs

OFC: 24.6mpg

Transmission: 4-speed manual, all syncromesh, rear wheel drive

Construction: pressed steel monocoque

Brakes: PA, hydraulic, discs/drum

Steering: rack and pinion. 3.5 turns lock to lock

Suspension F: Independent MacPherson strut, anti roll bar R: Semi-elliptic leaf springs

Wheels: 4 stud, 13in pressed steel, 165x13 Goodyear G800 tyres

Wheelbase: 98in

Track F: 52.5in, R: 51in

Overall length: 168.75in

Overall width: 62.5in

Overall height: 53.75in

Kerb weight: 18cwt

Fuel tank: 10 Imp gals

Production: March 1967-Aug 1970, 4,093 produced
Price new £1,068 2s 11d Inc. PT

Total production of all Cortina Mk ll variants: 1,027,869
