Ferrari Daytona Spider 1969-73
See specifications below illustration
Page 233
Ferrari Daytona Spider 1969-73 specifications

Engine (F251): V12, 4 cam, 24 valves, dry sump, lubrication, front mounted

Displacement: 268.5cui/4,390cc

Carburation: petrol, 6 Weber 40DC/20

Bore & Stroke: 3.19in/81mm x 2.8in/71mm

Compression ratio: 9.3 to 1

Max power: 352bhp at 7,500rpm

Max torque: 318 lb-ft (432Nm) at 5,500rpm

Maximum speed: 173mph/278km

Acceleration: 0-60mph 5.9secs 0-100mph 12secs

O.F.C.: 17mpg US/14mpg Imperial

Transmission: 5 speed manual, RWD

Construction: steel body on tubular frame chassis, aluminium bonnet, boot & door skins

Steering: Rack and pinion

Suspension: Independent coil and double wishbone all round

Wheels: Knock-on on 15in aluminium 5 spoke
Standard Tyres: 215/70 VR15


Wheelbase: 94.5in/2,440mm

Track: front 56.7in/1,440mm rear 56.1in/1,425mm

Length: 174,2in/4,425mm

Width (excl. mirrors): 69.3in/1760mm
Overall height: 49in/1,245mm

Tank capacity: 26.4 Imp gal/31 U.S. gal/120 litres

Curb Weight: 3,527lbs/1,600kg

365 GTB4 Production:
GTB4 (coupé) 1968-73: 1,284
GTS4 Spider (convertible) 1969-73: 122
Modena, Italy
