Fiat 500R 1972-75
See specifications below illustration
Page 229R
Fiat 500R 1972-75 specifications
air cooled two cylinder OHV
Capacity: 594cc
Bore: 73.5mm
Stroke: 70.00mm
Valves: 4, 2 per cylinder
Compression ratio: 7.5 to 1
Power: 23bhp at 4000rpm
Max speed: 100km/h / 62mph
0-90km/h: 43.3secs
0-50mph: 26.9secs
OFC: 18km/l / 48mpg
Transmission: 4 speed all syncromesh RWD
Construction: pressed steel unitary
Suspension, front: tranverse leaf, rear: independent coil and wishbone, telescopic shock absorbers
Wheels: 12in pressed steel

Dimensions & Weight
Wheelbase: 1,840mm/72.4in
Length: 2,970mm/116.9in
Width: 1,320mm/52in
Height: 1,325mm/52in
Track front: 1,120mm/45in
Rear: 1,137mm/49.5in
Kerb weight: 525kg / 1,157 lbs

1957-75, approx 3.6 million produced
