Jensen Healey 1972-76
See specifications below illustration
Page 234
Jensen Healey 1972-76 specifications

Engine (Lotus 907): 4 cylinder inline, 16 valve DOHC, aluminium head & block, longitudal

Bore & Stroke: 95.2mm x 69.3mm

Displacement: 1,973cc

Compression ratio: 8.4 to one

Carburettors: twin Delloreto DHLA 40

Max power: 140bhp at 6,500rpm,

Torque: 130 lbs/ft at 5,000rpm

Max speed: 119mph

0-60mph: 7.8secs

Overall fuel consumption: 21mpg (Imp.)

Transmission: RWD, 4-speed (Chrysler), all synchro, final drive: 3.73

Steering: rack and pinion, 33-34ft turning circle

Suspension: (Vauxhall Viva), Front: independent, coil & double wishbone, Rear: live axle, coil trailing and semi trailing arms, telescopic dampers

Brakes: PA, Girling hydraulic, front: 10in disc, rear: 1.75 x 9in drum

Construction: all steel, integral with pressed platform chassis

Wheels & tyres: alloy 5.5J x 13in, 185 x 13 tyres


Wheelbase: 92in

Track F: 53.2in, R: 52.5in

Overall length: 162in

Overall width: 63.2in

Overall height: 48in

Ground clearance: 5in

Kerb weight: 19cwt

Fuel tank: 11 Imp gal
