Porsche 912
See specifications below illustration
Page 272
Porsche 912 1965-69 specifications

Engine (Boxer 4): All aluminium, 4 Cylinder, horizontally mounted, 8 overhead valves, air cooled, Bore & stroke: 82.5mm x 74mm

Displacement: 1,582cc

Compression ratio: 9.3 to 1

Carburation: petrol 2 x Solex carbs

Maximum speed: 192km/h (119mph)

Acceleration: 0-96.5km/h (0-60mph) 11.9sec

Max power: 210.3kw (89bhp) at 5.800rpm

Max torque: 122Nm / 89 lb-ft at 5.800rpm

Drag coefficient: 0.39

Construction: pressed steel monocoque

Ave. fuel consumption: 30mpg US
Transmission: 4 forward speed manual, rear engined, rear wheel drive

Brakes front & rear: P.A. dual circuit, ventilated discsSuspension: Torsion bars

Steering: PA rack & pinion

Turning circle: 10.7m (35.1ft)

Wheels: Extra equipment 16in bolt-on aluminium (standard 15 x 4.5 J pressed steel)

Tyres front & rear: 165 x 15
Wheelbase: 2,210mm
Track front: 1,359mm, rear: 1,340mm
Overall length: 4,163mm
Overall width: 1,613mm
Overall height: 1,321mm
Ground clearance: 152mm
Tank capacity: 61.4 litres (16.2 US gal)
Unladen weight: 968kg (2,134 lbs)

912 production: April1965 to July 1969. Approx 36,000 produced, Stuttgart, Germany
