Sunbeam Tiger 1964-67
See specifications below illustration
Page 083F
Whilst the trademark owner has consented to the reproduction of its logo and emblems it has no connection with or responsibility for this drawing or for the technical data and gives no warranty as to its accuracy.

Sunbeam Tiger 1964-67 specifications

Engine: Ford Vee 8, ohv
Displacement: 4,281cc
Bore & Stroke: 86.5mm x 73mm
Compression ratio: 8.8 to 1
Carburettor: single Holley 1848
Power output: 164bhp at 4,400rpm
Maximum torque: 258lb at 2,200rpm
Maximum speed: 120mph
Acceleration 0-60mph: 8.6secs
Overall fuel consumption: 30-35mpg
Transmission: RWD, 4-speed all syncromesh manual
Construction: pressed steel monocoque reinforced underneath with a box-like structure similar to Hillman Husky
Brakes: hydraulic, front: 9.85in disc, rear: 9in drum
Steering: rack & pinion
Suspension: front: ind. coil & wishbone, rear: Semi-elleptic leaf, telescopic dampers Wheels: 4 stud, 13in, pressed steel disc
Wheelbase: 86in
Track front: 51.7in
Track rear: 48.5in
Overall length: 155.3in
Overall width: 60.5in
Overall height: 51.5in
Ground Clearance: 4.3in
Kerb weight: 2,540lbs
Fuel tank: 11 Imp. gals

Tiger Production 1964-67
Total built: 7,083
Mk1 & Mk1A 1964-67: 6,450
MkII 1967: 663 West Bromwich, Staffordshire, England
