See specifications below illustration
Page 107B
Engine
Rearmounted flat 4, ohv, air cooled
Displacement: 1,192cc
Bore & stroke: 77mm, x 64mm
Compression ratio: 8.5 to 1
Carburettors: single Solex 28 PICT-1
Power output: 22bhp at 3,400 rpm
Transmission
Rear wheel drive
Clutch: single dry plate
Gearbox: 4 speed
Performance
Maximum speed: 87mph
Acceleration: 0-60mph 21.7sec
Approx fuel consumption: 30mpg
Brakes
Hydraulic, drums all round
mechanical handbrake
Steering
Worm and roller
Suspension
Torsion bars, fully independent
Rearmounted flat 4, ohv, air cooled
Displacement: 1,192cc
Bore & stroke: 77mm, x 64mm
Compression ratio: 8.5 to 1
Carburettors: single Solex 28 PICT-1
Power output: 22bhp at 3,400 rpm
Transmission
Rear wheel drive
Clutch: single dry plate
Gearbox: 4 speed
Performance
Maximum speed: 87mph
Acceleration: 0-60mph 21.7sec
Approx fuel consumption: 30mpg
Brakes
Hydraulic, drums all round
mechanical handbrake
Steering
Worm and roller
Suspension
Torsion bars, fully independent
Wheels
4.5Jx15 disc, 5.60 x 15 radial tyres
Construction
All metal body on pressed steel backbone chassis (Beetle base)
Dimensions
Wheelbase: 94.5in
Front track: 50.8in
Rear track: 49.2
Ground clearance: 5.6in
Length:
Width: 60.8in
Height: 59in
Kerb weight 1,930 lb
Production
1955-71 over 445,000 built
Designed by Luigi Segre
4.5Jx15 disc, 5.60 x 15 radial tyres
Construction
All metal body on pressed steel backbone chassis (Beetle base)
Dimensions
Wheelbase: 94.5in
Front track: 50.8in
Rear track: 49.2
Ground clearance: 5.6in
Length:
Width: 60.8in
Height: 59in
Kerb weight 1,930 lb
Production
1955-71 over 445,000 built
Designed by Luigi Segre
