MGF 1.8i 1995-2002
See specifications below illustration
Page 183
MG TF 160 Specifications
Cylinders: 4 in line
Bore: 80mm
Stroke: 89.3mm
Displacement: 1796cc
Valves: 4 per cylinder DOHC
Compression ratio: 10.5:1
Carburation: programmed injection
Max power: 160ps at 6900rpm

Maximum speed: 120mph
Acceleration: 0-60 mph 8.5secs
Overall fuel consumption: 38.3mpg

Clutch: single dry-plate diaphragm
Gearbox: 5-speed, manual sports ratio
Ratios: 5th 0.765, 4th 1.033, 3rd 1.308, 2nd 2.842, 1st 3.167, reverse 3.00
Final Drive: 4.200

Monocoque steel construction,
2 seat convertible

Front: Double wishbone inter-connected Hydrogas, shock absorbers and anti-roll bar
Rear: Double wishbone, brake reaction rods, inter-connected Hydrogas, shock absorbers and anti-roll bar

Rack and pinion, power assisted
3.1 turns lock to lock

Front: 9.5in ventilated disc
Rear: 9.5in solid disc
Bosch 5.3 ABS

Wheels & Tyres
15in 8 spoke alloy, with 185/55 VR15(front), 205/50 VR15(rear)

Wheelbase: 93.8in
Track - front: 55.1in
Track - rear: 55.5in
Overall length: 154in
Overall width: 70in
Height: 49.65in
Ground clearance: 5in
Turning circle: 34.7ft
Tank capacity: 11gals
Cd: 0.36
Production 1995-2002
BMW Rover Group (1995-1999)
MG Rover (2000-2002)
77,212 built
