MG TF 135
See specifications and my Christmas 2003 card below illustration
Page 223A
MG TF 135 Specifications
Engine
Cylinders: 4 in line
Bore & Stroke: 80mm x 89.3mm
Displacement: 1,796cc
Valves: 4 per cylinder DOHC
Compression ratio: 10.5 to1
Carburation: programmed injection
Max power: 134bhp at 6,750rpm
Torque: 165Nm/16.8kgm at 5,000

Performance
Maximum speed: 127 mph
Acceleration: 0-60 mph 8.2secs
Overall fuel consumption: 35.6mpg

Transmission
Clutch: single dry-plate diaphragm
Gearbox: 5-speed, manual

Body/Chassis
Monocoque steel construction,
2 seat convertible

Steering
Rack and pinion, power assisted
2.81 turns lock to lock
Brakes
Front: 12in ventilated disc
Rear: 9.4in solid disc
Bosch type ABS


Suspension
Front: Double wishbone coil spring
Rear: multilink with coil springs spring, gas filled telescopic dampers all round

Wheels & Tyres
7J x 16in bolt on aluminium
with 195/45 ZR16(front) and
215/40 ZR16(rear) low profile tyres

Dimensions
Wheelbase: 93.8in
Track - front: 55.2in
Track - rear: 55.5in
Overall length: 155.2in
Overall width: 71.32in
Height: 49.65in
Ground clearance: 5in
Turning circle: 34.7ft
Tank capacity: 11gals
Cd: 0.36
Weight: 1,150kg
after-marhket rear lights version available:
Specifications?
