MG ZR 2001-04
See specifications below illustration
Page 240
MG ZR 2001-04 Specifications
Engine (K1.8): straight 4, DOHC, 16 valves, transverse mounted, aluminium block & head, catalytic converter
Displacement: 1,796cc
Compression ratio: 10.5 to1
Max power: 160Ps / 158bhp at 7,000rpm
Carburation: petrol injection, MEMS3
Maximum speed: 130mph / 219km/h
Acceleration 0-60 mph: 7.4secs
Overall fuel consumption: 37mpg / 13.3km/l
Transmission: FWD, 5-speed, manual, single dry-plate clutch diaphragm
Final drive ratio: 4.20
Body/Chassis: Monocoque steel construction
Steering: Rack and pinion, power assisted
Turning Circle: 37.7ft / l1.6m
Brakes F: 262mm ventilated disc, R: 239mm solid disc
Suspension F: MacPherson strut, anti roll bar R: independent coil springs gas
Wheels & Tyres: 7J x 17in alloy with 205/45 R17 tyres
Dimensions
Wheelbase: 98.4in / 2,500mm
Track (F): 58in / 1,472mm
Track (R): 57.4in / 1,457mm
Overall length: 157.9in / 4,011mm
Width: 66.5in / 1,688mm
Height: 55.1in / 1,400mm
Tank capacity: 11 UKgals / 50L
Weight: 2,523 lb / 1,145kg
