1964 E-Type low drag - Lindner/ Nocker
See specifications below illustration
Jaguar E-Type lightweight specifications
Lightweight: No.5
Chassis number: S850662
Engine number: RA1347-9S
Gearbox number: EB9642CR
Body number: R5863

Engine: aluminium, 6 Cylinder inline, dohc
Displacement: 3,781cc
Bore & Stroke: 92mm x 106mm
Fuel Feed: Lucas fuel injection
Power output: 344bhp at 5,750rpm
Maximum Speed: 170mph
Transmission: RWD, ZF 5-speed manual

Construction: steel monocoque and aluminium, square tube subframe at front, pressed steel subframe at rear

Brakes: Dunlop discs all round, inboard mounted at rear
Steering: rack and pinion,
Suspension F/R: independent with torsion bars, wishbones, anti roll bar/independent, double spring/shock units, tranverse lower links, longitudinal radius arms
Wheels: 15in knock-on vented disc
Wheelbase: 96.1in Track F&R: 50in
Length: 174in Width: 65in Height: 47in
